APPLICATION EXAMPLE
ME4a with STELLA-T4
For help with an application simulation using our optics, or to make a request about what application you want us to cover next, contact Tech support
SETUP:
| Lighting class: | ME4a |
| Optics: | STELLA-T4 |
| LED: | CXA2590 |
| Road width: | 41 m |
| Number of lanes: | 12 |
| Arrangement: | Two-sided |
| Luminous flux (LEDs): | 11 000 lm |
| Pole distance: | 24 m |
| Mounting height: | 12 m |
| FN14645_STELLA-T4 | ||
| FN15187_STELLA-T4 |
