Luminaire examples
Luminaires with DAISY-MINI-3X1
For help with an application simulation using our optics, or to make a request about what application you want us to cover next, contact Tech support
Luminaire 3X1
| Optics: | DAISY-MINI-3X1 |
| Number of optics: | 1 |
| LED: | LM281B+ Pro |
| Number of LEDs: | 6 |
| Output: | 420 lm |
| Power (luminaire): | 3 W |
| Efficiency (w/o driver): | 140 lm/W |
Luminaires 6X1 and 3X2
| Optics: | DAISY-MINI-3X1 |
| Number of optics: | 2 |
| LED: | LM281B+ Pro |
| Number of LEDs: | 12 |
| Output: | 840 lm |
| Power (luminaire): | 6 W |
| Efficiency (w/o driver): | 140 lm/W |
Luminaires 9X1 and 3X3
| Optics: | DAISY-MINI-3X1 |
| Number of optics: | 3 |
| LED: | LM281B+ Pro |
| Number of LEDs: | 18 |
| Output: | 1260 lm |
| Power (luminaire): | 9 W |
| Efficiency (w/o driver): | 140 lm/W |
Luminaires with DAISY-MINI-3X1
For help with an application simulation using our optics, or to make a request about what application you want us to cover next, contact Tech support
The information contained herein is the property of LEDiL Oy, Joensuunkatu 13, FI-24100 SALO, Finland and is subject to change without notice. Please visit lediloptics.cn for additional information, such as the latest photometric files, 3D mechanical models, and application notes relating to handling, gluing and taping.
