LEDiL 光学器件和新型 B+W Hybrid 630 COB 承托器
与无限多个 COB 的连通性
Bender + Wirth 推出了一款新型 COB 承托器系列 Hybrid 630,它结合了注射成型的设计灵活性与云母的热性能。 Hybrid 630 能兼容的 LEDiL 光学器件范围很广,具有与无限多个 COB 的兼容性。初始系列包括 120 种不同型号。 此混合承托器由带光学接口的外壳和 COB 承托器组成。总共有 5 个外壳与不同的 LEDiL 光学器件兼容和 11 个 COB 承托器,可提供 12.5 mm x 12.5 mm 到 28 x 28 mm COB 封装尺寸的连通性。五个外壳和兼容的 LEDiL 光学器件:
Hekla 外壳 | BARBARA-G2 MIRELLA-G2 BROOKE-G2 CARMEN RONDA-C WINNIE-C ILONA ZORYA-SC-C | |
3Hook 外壳 | ANGELA ANGELETTE ANGELINA MOLLY RONDA (with HOLDER A) | |
Lena 外壳 | LENA LENINA | |
LowProfile 外壳 | STELLA | |
Bayonet50 外壳 | ANGELA-B ANGELINA-B ANGELETTE-B ZORYA-SC-B |
所有详细信息都可以从 变体图表中找到。
